Simulation Lab
- HP Desktop PCs Intel Core-i7 8700, 3.2 GHz 8GB Ram (30 Nos.)
- HP Desktop PC’s Intel Core-i7 4770, 3.4GHz, 4GB RAM (02 Nos.)
- DSP Trainer Kit (Sands make, TMS320C5402 Based) DSK6713 (6 Nos.)
- Bit Codec (For DSP trainer Kit) (01 No.)
- ADC/DAC Module (For DSP trainer Kit) (01 No.)
Communication Lab
- Modulation & Demodulation Kit - AM, FM, ASK, FSK (12 Nos.)
- Spectrum Analyzer - 500 MHz (1 No.)
- D.S.O- 40, 60, 200MHz (4 Nos.)
- RF Synthesizer (3Nos.)
- Dual Channel CRO 30MHz (10 Nos.)
Digital Lab
- Advance Digital Trainer–Excel (15 Nos.)
- Universal IC Tester (2 Nos.)
- Advance Digital Trainer- (10 Nos.)
- Voltage Stabilizer- 5KVA (1 No.)
Electronics Lab
- Dual Channel CRO 20/30 MHz (27Nos.)
- Function Generator -DC- 3.3 MHz, 20Vpp (30 Nos.)
- DC Power Supply - 2x30V-1A, ±15V-2A (39 Nos.)
- DSO 40MHz (1 No.)
PCB / Microcontroller Lab
- 8085 trainer kits (20 Nos.)
- Trainer Kit 8086 (5 Nos.)
- Study Card - 8251, 8253, 8255, 8257, 8259, 8279, stepper motor control (5 Nos. each)
- Transformer Winding Machine -21x14 (2 Nos.)
- Photo Resist DIP Coating Machine (1 No.)
Research & Project Lab
- HP Pro 400G2MT- i7, 4GB RAM, 3.4 GHz (17 Nos.)
- HP 3090 -i5 2GB RAM 200GBHDD (6 Nos.)
- MATLAB Campus Wide License
- Orcad Pspice Circuit Simulator-A version 15.7 (Orcad capture -5 user licenses, Orcad Pspice A/D-2 user licenses)
- Mentor Graphics HEP-2 Tools & Xilinx FPGA Tools with Sparten 3E Starter Kits (HDL Designer, Modelsim, Leonardo Spectrum ASIC, Precision Synthesis Tool (30 user licenses)
